Setting up your GPS TrackPack device
Overview
Documenting the path of K-9 tracks and suspect searches, is normally a task that
requires several steps of manual design work to get an image that can be attached
to the user’s Usage or Training reports. The KANINE Software GPS Data logger
enables the user to effortlessly create a map (in either satellite or map format) of the
logged K-9 track that can easily be converted to an image file, which can then be
attached to a KANINE software Usage or Training report.
We have gone to great lengths to make the GPS data download and conversion
process as user friendly as possible. When we first began working on this project we
knew that we would have to accomplish two basic tasks:
•
Build all GPS processes directly into the KANINE software.
•
Make the process as absolutely simple as possible.
We feel that we accomplished both of these tasks with the GPS TrackPack. The unit is easy to use and
reliable. The process by which the user downloads the data and converts it into a map is easy and can be
accomplished with a single mouse click. We have found that our users enjoy the ease of use and
functionality of the TrackPack Unit and that support for the unit has been very low.
Download computer
Every agency must have certain files installed to at least one computer to enable the downloading and
conversion of raw GPS data. Multi-user agencies need not have all of the download files installed on
every KANINE user’s machines. GPS files can be downloaded on a central computer and then transferred
to the user’s computer via a USB drive or a network connection.
File Installation (For computers used to download GPS files)
The following files need to be installed on any computer that will be used to download and convert the
GPS data from the logger unit. All necessary files are included on the provided CD, but can be
downloaded from the locations below as well.
•
GPS Device driver- http://www.codebluedesigns.com/downloads/k95/gps_driver.zip
o
The GPS driver is required to be installed on any computer that needs to interact with the
GPS device. This driver allows Windows to identify and work with the GPS Unit. To install the
driver, perform the following steps:
1.
Download the installation file, or insert the provided CD into your computer’s CD drive.
2.
Plug the GPS unit into your computer using the provided USB cord.
3.
Turn the GPS unit on. Your computer should automatically attempt to install the driver
for the GPS unit. When the device wizard opens you must follow the steps in the wizard
to point to either the download and unzipped folder or onto the CD into the
GPS_Device_Driver folder and then into the folder that matches your computer’s
operating system. For instance, for a Windows 7 computer you would browse into the
‘Vista_Win7’ folder and then select the appropriate file. In this case you can either
select the 64 based file or the non 64 based file.
•
Java Runtime Files- http://www.java.com/en/download/manual.jsp#win
o
Because the Java runtime is used for many computer applications, your computer might
already have the Java runtime installed. You can check by going into your computer’s ‘Control
Panel’ and then into ‘Add Remove Programs’ and looking for an entry for the Java runtime. If
an entry already exists, you should not have to perform this install.
•
Google Earth (Optional)- http://earth.google.com/intl/en/download-earth.html
o
The installation of Google Earth is not mandatory and most GPS functionality can be
performed right inside of the KANINE software itself using Google Maps. Installing Google
Earth, however, provides some additional map modification functionality.
*NOTE: CHARGE YOUR GPS DEVICE FOR AT LEAST 3 HOURS BEFORE USING.*
